Buzzer Loudspeaker Samsung Galaxy A13 A15 A16

Buzzer Loudspeaker for Samsung Galaxy A13, A15 and A16: Sound and Ringtone Restoration

The buzzer loudspeaker for Samsung Galaxy A13, Galaxy A15 and Galaxy A16 restores multimedia audio playback, ringtones and loudspeaker functionality on the device. This part replaces a worn or silent lower loudspeaker module, restoring acoustics accurately.

Technical Specifications

• Part type: Lower buzzer loudspeaker
• Compatibility: Samsung Galaxy A13 (SM-A135F, SM-A137F, SM-A136B); Samsung Galaxy A15 (SM-A155F, SM-A156B); Samsung Galaxy A16 (SM-A165F, SM-A166B)
• Quality: Compatible

When to Replace

• Distorted multimedia sound, with metallic noise or very low volume
• The phone does not ring when receiving calls or notifications
• Hands-free mode (loudspeaker) with no sound output during calls — confirm diagnosis
• Total absence of audio in videos and games — confirm diagnosis

Notes for the Technician

• Test before applying: connect the part to the device and confirm it works before fixing or gluing it permanently. Thus, if there is any issue, return or warranty is handled quickly and simply.
• Difficulty: Medium
• Access achieved by removing the back cover and the intermediate frame to reach the lower chassis area
• Clean dust residue on the chassis acoustic grille before positioning the new buzzer
• Check the alignment of the pressure contacts with the charging board to ensure correct electrical contact
• Test ringtone and loudspeaker playback after tightening the frame screws

What Distinguishes This Version

This high-end compatible version was designed with precise tolerances to fit without gaps in the lower chassis area. It is the suitable choice for technicians seeking an economical and functional intervention on the workbench.

Frequently Asked Questions

Is this buzzer compatible with all variants of the Galaxy A13, A15 and A16?
Yes, the module was developed to fit the lower structure of both 4G and 5G variants of the Samsung Galaxy A13, Galaxy A15 and Galaxy A16 models.

Does this component resolve issues with in-ear call sound?
No. This lower loudspeaker is intended for multimedia sound, ringtones and loudspeaker; in-ear calls use the upper earpiece.
