Charging Port and SIM Reader Honor 200 Pro

Charging Port and SIM Reader for Honor 200 Pro: Connectivity and Stable Charging

This charging sub-board with integrated SIM card reader is designed to repair power failures and network reading issues on the Honor 200 Pro. The module restores stable communication via the USB-C connector and the operation of the card tray.

Technical Specifications

• Part type: Charging port and SIM card reader
• Compatibility: Honor 200 Pro (ELP-AN00)
• Quality: Premium

When to Replace

• The phone does not charge or has poor contact in the USB-C cable
• The computer does not recognise the data connection via cable
• "No SIM Card" error or card reading failure
• Mechanical poor contact in the charging input

Notes for the Technician

• Test before applying: before fixing, confirm charging and, if applicable, data transfer and the microphone. Thus, if there is any issue, the return or warranty is handled quickly and simply.
• Installation difficulty: Medium
• Requires opening the back cover with moderate heat and unscrewing the lower shielding
• Disconnect the battery before handling the flexible interconnection cables
• Check the integrity of the sealing rubbers and the alignment of the lower microphone

What Distinguishes This Version

This is a Premium level part, representing the top option in the compatible replacement segment. It is the suitable solution for technicians and workshops looking for a reliable component for a professional intervention without compromising the budget.

Frequently Asked Questions

Does this board include the integrated SIM card reader?
Yes, the component includes both the USB-C charging socket and the SIM card reader soldered on the same lower board of the Honor 200 Pro.

Does the repair require soldering?
No, replacement is done via pressure connectors on the main board and the equipment's flexible connection cables.
