Hard OLED Screen iPhone 11 Pro

Hard OLED Screen for iPhone 11 Pro: Real Blacks and Vivid Colours

The Hard OLED screen for iPhone 11 Pro is suitable for replacing a broken or faulty display on the device. This replacement OLED panel ensures precise touch response and high contrast during daily use.

Technical Specifications

• Part type: Complete screen with touch panel
• Compatibility: iPhone 11 Pro (A2160, A2215, A2217)
• Reference: DP-HO-IP11P
• Technology: Hard OLED (rigid glass base)
• Quality: Compatible

When to Replace

• Front glass broken or with surface cracks
• Panel with coloured vertical lines or dark spots
• Completely black display with no image output — confirm the diagnosis
• Touch response failures or ghost touches in certain areas

Notes for the Technician

• Test before applying: connect the screen to the device without gluing it and confirm image, touch across the entire area and brightness, keeping the protective films on. Thus, if there is any issue, the return or warranty is handled simply and quickly.
• Installation difficulty: Medium
• Requires removing the two bottom pentalobe screws and cautiously opening from the right side
• Necessary to transfer the proximity sensor and earpiece assembly from the damaged screen
• Always disconnect the battery before handling the display flex cables to prevent electrical damage
• The sealing adhesive is sold separately

What Distinguishes This Version

This version uses Hard OLED technology, offering vivid colours and deep blacks on a rigid glass structure. It is a balanced option for repairs with excellent value for money, positioning itself above Incell panels and being more accessible than Soft OLED options.

Frequently Asked Questions

What is the difference between Hard OLED and Soft OLED in this model?
Hard OLED is built on a rigid glass substrate, ensuring pure blacks and excellent contrast, although it is more vulnerable to impacts than Soft OLED flexible panels.

Does this screen also fit the iPhone 11 or iPhone 11 Pro Max?
No. This component is exclusive to the iPhone 11 Pro (models A2160, A2215 and A2217), featuring dimensions and connections incompatible with the other variants in the range.
