iPhone 11 Pro Max Soft OLED Screen and Touch

Soft OLED Screen for iPhone 11 Pro Max: Flexible Panel and Precise Touch

This touch screen module with a flexible panel has been developed to replace the damaged display on the iPhone 11 Pro Max. A replacement OLED panel solution designed to restore the mobile phone's touch response and visual display.

Technical Specifications

• Part type: Touch screen and display
• Compatibility: iPhone 11 Pro Max (A2161, A2218, A2220)
• Reference: DI11PROMAXOLED
• Technology: Soft OLED
• Quality: Compatible

When to Replace

• Front glass broken or scratched after a drop.
• Panel with no image, completely dark or with vertical lines.
• Areas of the screen not responding to touch or ghost touches.
• Black spots or loss of illumination in the image.

Notes for the Technician

• Test before applying: connect the screen to the device without sticking it and confirm the image, touch across the entire area and brightness, keeping the protective films on. Thus, if there is any issue, the return or warranty is handled quickly and simply.
• Installation difficulty: Medium.
• Opening from the front panel, removing the two bottom screws near the charging port.
• Necessary to transfer the top sensor flex from the damaged screen with extra care.
• The adhesive seal for a watertight closure is sold separately.

What Distinguishes This Version

This Soft OLED version uses a flexible OLED panel with the correct thickness, good colours and high mechanical impact resistance. It stands as the best compatible option from Micro Wire, being the ideal choice for the professional technician and for repairs that require a rigorous finish.

Frequently Asked Questions

Is this screen compatible with the standard iPhone 11 Pro?

No, this model is intended exclusively for the iPhone 11 Pro Max, and is not compatible with the standard Pro variant.

The mobile turns on but shows no image, does replacing the screen resolve it?

In the vast majority of occurrences, the issue lies in the damaged internal display, however confirm the diagnosis to rule out anomalies on the main board.

Each unit is tested by Micro Wire before dispatch, with fast shipping from Portugal. If you do not want to repair it we can do it for you.
