Samsung Galaxy A20E Charging Port

Samsung Galaxy A20e Charging Port: USB Connection and Charging Repair

The charging port for the Samsung Galaxy A20e restores power delivery and data communication with the computer. This subboard with USB Type-C charging connector replaces the module damaged by wear, moisture or bent pins.

Technical Specifications

• Part type: Subboard with USB Type-C charging port
• Compatibility: Samsung Galaxy A20e (SM-A202F, SM-A202K)
• Quality: Compatible

When to Replace

• The mobile does not detect the charging cable or only charges in a specific position.
• Poor contact when plugging in the USB Type-C connector or visible play in the port.
• The computer does not recognise the device via the data cable — check the diagnosis.
• Signs of moisture corrosion or bent internal pins in the charging port.

Notes for the Technician

• Test before applying: before fixing, check charging and, if applicable, data transfer and microphone. Thus, if there is any issue, return or warranty is handled quickly and simply.
• Difficulty: Medium.
• The intervention requires removing the back cover and middle frame to access the lower area of the device.
• Disconnect the battery before releasing the intermediate flex cable and antenna coaxial cable connected to this board.
• Check the alignment of the microphone and USB port sealing rubber when fitting the part into the chassis.

What Distinguishes This Version

This is a high-grade compatible replacement part designed specifically for direct functional workbench replacement. It is the suitable choice for technicians looking for a reliable and economical solution for everyday repairs.

Frequently Asked Questions

Is this charging board compatible with the regular Samsung Galaxy A20?
No. The dimensions and internal connectors of the Samsung Galaxy A20e (SM-A202F) differ from the standard Galaxy A20 (SM-A205F), so this part serves exclusively the A20e version.

Is it necessary to solder any component to install this charging port?
No. The part is supplied as a complete subboard, making the connection to the main circuit via the connecting flex cable and pressure snaps.
