Screen LCD iPhone 17 Pro Max LTPS Selected

LTPS LCD Screen for iPhone 17 Pro Max: Sharp Image and Precise Response

This is a replacement screen for the iPhone 17 Pro Max, designed to solve image and touch problems. If your device has a broken glass, panel stains or the touch does not work correctly, this LCD display allows you to restore the functionality and appearance of your mobile phone.

Technical Specifications

• Part type: LCD Screen with Touch
• Compatibility: iPhone 17 Pro Max (A3257, A3525, A3526, A3527)
• Reference: DP-IPH17PM-INC
• Technology: LCD LTPS (Low-Temperature Polycrystalline Silicon)
• Quality: Micro Wire Selected

When to Replace

• The screen glass is broken, cracked or has deep scratches.
• The image shows stains, vertical lines or dead pixels.
• The screen is completely black or white, but the phone emits sounds.
• The touch does not respond in some areas or across the entire surface.
• Colours are distorted or brightness is irregular.

Notes for the Technician

• Test before applying: connect the screen to the device without gluing it and confirm image, touch across the entire area and brightness, keeping the protective films. This way, if there is any problem, the return or warranty is handled quickly and simply.
• Repair difficulty: Advanced.
• It is necessary to transfer the earpiece and sensor assembly from the previous screen to maintain associated functionalities.
• To ensure water resistance, it is recommended to apply a new screen adhesive, sold separately.
• Before starting the repair, make sure the device is updated to the latest iOS version.
• After installation, the part can be activated via Apple Diagnostics so that the system recognises it correctly.

Micro Wire Selected Range

Micro Wire Selected range parts are individually selected components validated in our laboratory to ensure reliable performance. This is the same reference that the Micro Wire technical team uses in repairs carried out in the store, ensuring full compatibility with the indicated device. The part is ready to install, without the need for complex additional configurations.

Frequently Asked Questions

Is this screen compatible with the iPhone 17 Pro?

No, this component was designed specifically for the iPhone 17 Pro Max model. The dimensions and connectors are different and do not fit other models.

After replacement, will iOS display any warning message?

This part can be activated via Apple Diagnostics. After this procedure, iOS recognises it as a used part, not displaying the "unknown part" message.

Each screen is tested by Micro Wire before shipping to ensure you receive a functional product. We offer fast shipping from Portugal. If you do not want to repair it, we can do it for you.
