Earpiece Speaker Honor Magic 5 Pro

Earpiece Speaker for Honor Magic 5 Pro: Superior Audio Restoration

The earpiece speaker for the Honor Magic 5 Pro restores front audio output during voice communications. This earpiece speaker replaces the faulty module, eliminating sound cuts and parasitic noise during conversation.

Technical Specifications

• Part type: Earpiece speaker
• Compatibility: Honor Magic 5 Pro (PGT-AN10, PGT-N19)
• Quality: Premium

When to Replace

• No sound from the earpiece during phone calls
• Distorted audio, with crackling or popping during conversation
• Extremely low call volume even at maximum level
• Intermittent sound when moving the mobile phone during the call — confirm the diagnosis

Notes for the Technician

• Test before applying: connect the part to the equipment and confirm its operation before securing or gluing it permanently. Thus, if there is any problem, the return or warranty is handled simply and quickly.
• Installation difficulty: Medium
• Accessing the earpiece requires removing the back cover and upper shielding modules
• Clean the audio output grille on the chassis before seating the new module to prevent acoustic obstructions
• Check the correct alignment of the pressure contacts on the main board before final closure of the equipment

What Distinguishes This Version

Esta peça de qualidade Premium posiciona-se no nível mais alto do segmento aftermarket. É a escolha indicada para técnicos que procuram fiabilidade de encaixe e restituição acústica precisa em reparações exigentes.

Frequently Asked Questions

Does this earpiece solve sound problems in the lower loudspeaker?
No. This component is exclusively the upper call loudspeaker near the ear, not the main multimedia loudspeaker.

Is it necessary to solder the component during replacement on the Honor Magic 5 Pro?
No, the connection to the board is made via pressure contacts, dispensing with any soldering point.
