Rear Camera Samsung Galaxy A22 4G A33 A34

Rear Camera for Galaxy A22 4G, A33 and A34: Photography and Focus Replacement

This rear camera is intended for replacing a faulty photographic module in compatible Samsung smartphones, restoring correct image capture. It is a genuine Samsung pulled part, recommended for repairing focus failures or unexpected closure of the photo application in the mobile phone.

Technical Specifications

• Part type: Rear camera module
• Compatibility: Galaxy A22 4G (SM-A225F); Galaxy A33 5G (SM-A336B); Galaxy A34 5G (SM-A346B)
• Part code: GH96-14454A
• Quality: Original — Pulled

When to Replace

• The camera application closes by itself or shows a black screen when opening the rear sensor.
• Blurred photographs, continuous shaking or inability to focus up close.
• Fixed spots, internal lens scratches or dark spots visible in all captures.
• Failure when switching between different photography or video modes — confirm diagnosis.

Notes for the Technician

• Test before applying: connect the part to the device and confirm its operation before permanently fixing or gluing it. Thus, if there is any issue, the return or warranty is handled quickly and simply.
• Intervention difficulty: Medium.
• Opening the mobile phone is done via the back cover, requiring moderate heat and new adhesive for final sealing (sold separately).
• Disconnect the battery before handling or unplugging the camera FPC connector on the main board to prevent short circuits.
• Avoid touching the module lens directly to prevent transferring grease or dust that affects image quality.

What Distinguishes This Version

As this is a recovered module from equipment, it maintains the same manufacturing standards and alignment as the factory component. It is the indicated option for technicians who want a reliable repair and exact replacement of image parameters.

Frequently Asked Questions

Is part GH96-14454A compatible with the three indicated models?
Yes, this part was designed to share direct compatibility between the Galaxy A22 4G, Galaxy A33 5G and Galaxy A34 5G.

Is it necessary to calibrate the camera via software after installation?
Calibration by proprietary software is not required; simply connect the FPC connector and test the operation of photography and focus after assembly.
